Mobile Phone Signal Jammer Designed For Qatar Emiri Diwan Palace
ZD-GR001/5G/QAT Mobile Signal Jammer
- General Description
ZD-GR001/5G/QAT Mobile Signal Jammer is specially designed and manufactured for high-level Qatar
conference room.
The product applied intelligent digital jamming technology. It can
jam all kinds of current mobile signals include 4G, 5G and WIFI.
This product can classify different target signals and then jam
them. It uses low power to achieve long jamming distance.
Therefore, this technique has high efficiency and protects users
from large radiation. The device has properties of small volume and
light weight which makes it convenient to carry.
This product is widely used to ensure security of nation defence,
military information, government department and other department.
It prevents mobile phone leak and eavesdropping which purifies
environment of conference and office.
- Application
¨Military, public security, government, other departments, office
and conference room
¨Special place: court, prison and detention house
¨Public place:Conference centre, music hall, cinema, library,
classroom, examination
room.
¨Other required places.
- Features
¨ This jammer can jam all kinds of current mobile signals include
2G, 3G, 4G, 5G mobile
signals and 2.4G, 5.8G WIFI signal. It can blocks mobile signal
completely.
¨ It uses intelligent digital jamming technology to replace the
barrage jamming which
makes jamming efficiency higher and reliable. This jammer can block
signal effectively.
¨ The intelligent jamming technology also makes the output powerof
jammer close to
mobile phone. It protects people from radiation.
¨ It is an environment friendly product that has power of 1W(same
as mobile phone
power) for each band.
¨ High quailty directional antenna with outstanding accuracy makes
it easy to control directions. And communications outside of
jamming area will not be disrupted.
4. Technical specifications
Jamming bands (Qatar bands) | 781～821MHz(2G) 925～960MHz(GSM900), 1805～1880 MHz(2G), 2110～2170 MHz(3G), 2570～2690MHz (4G) 3400～3600MHz(5G), 3600～3800MHz (5G), 1525-1627MHz (satellite telephone, 2W) 2400-2500MHz (2.4G WiFi), 5150-5850MHz (5.8G WiFi). |
| Total RF power | 30W±1dBm |
| Radiation angle | directional,horizontal angle 75° |
| Jamming distance | 25m(visible,mobile signal strength: GSM:-65dBm,3G:-75dBm,4G:-90dBm,
all the above datas are signal strength shown in mobile phone) |
| Power supply | 220VAC±20%,50-60Hz / UPS (4KW) |
| Dimension (L´W´H) | 358´255´80 |
| Weight | 5Kg |
| Operation temperature | -10 ~ +45 |
